The advantage properties of aluminum alloy are light weight, excellent electrical and thermal conductivity, high corrosion resistance and ductility.

Aluminium Foil

Alloy Series	1/2/3/5/6/7/8xxx series
Common Alloy	1100/1200/1050/1060/1070/1235/3003/3004/3104/5052/8011/8079/8006 and etc. Others are also available
Temper	F/O/H12/H14/H16/H18/H22/H24/H26/H28/H32/H34/H36/H38
Thickness	0.15~6.00mm
Width	600 ~ 2,600 mm(Standard Size:914mm,1000mm,1200mm,1219mm,1250mm,1500mm)
Weight	3-8 tons per coil or as request
Surface Finish	Mill finish (unless otherwise specified), Color Coated, or Stucco Embossed
Surface Protection	With PE/PVC filming on main side (if specified)
Technique	Cold Rolled ,Hot rolled
Forms	Coils, Rolls,Strips, Perforated Steel Coils, Checkered Steel Coils.
Coil Inside Diameter	305mm,405mm,505mm or per request
MOQ	5MT per size, total 20MT for one order
Quality of Material	Totally free from defects like white rust,roll marks,edge damage,camber,dents,holes,break lines,scratches and free from coil set.
Production Capacity	5000 tons per month
Delivery Time	Standard size:7-10 workdaysCustomized Products :15-30 workdays
Customized Service	OEM and ODM
Certification	ISO9001, SGS, BV,CE,SGS
Trade Terms	EXW,FOB,CIF,CFR,DDP,DDU
Loading Port	Tianjin,Shanghai,Qingdao,etc

Alloy Designation and Temper:

Standard Specification: GB/T 3880, ASTM B209, EN485

Alloy	Temper
1xxx: 1050, 1050A, 1060, 1100	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
3xxx: 3003, 3004, 3005, 3105	O, H12, H14, H16, H18, H22, H24, H26, H28, H111
5xxx: 5005, 5052, 5754, 5083, 5086, 5182, 5049, 5251, 5454	O, H22, H24, H26, H28, H32, H34, H36, H38, H111
6xxx: 6061, 6082	T4, T6, T451, T651
2xxx: 2024	T3, T351, T4
7xxx: 7075	T6, T651

Chemical Composition (For Reference)

Chemical Composition conforms to Chinese, American and European standard specification

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others:Each	Others:Total	Al: Min.
1050	0.25	0.40	0.05	0.05	0.05	-	0.05	0.03	0.03	-	99.50
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	0.03	-	99.60
1100	0.95 Si + Fe		0.05~0.20	0.05	-	-	0.10	-	0.05	0.15	99.0
3003	0.60	0.70	0.05~0.20	1.0~1.5	-	-	0.10	-	0.05	0.15	remainder
3004	0.30	0.70	0.25	1.0~1.5	0.8~1.3	-	0.25	-	0.05	0.15	remainder
3005	0.60	0.70	0.30	1.0~1.5	0.2~0.6	0.10	0.25	0.10	0.05	0.15	remainder
5005	0.30	0.70	0.20	0.20	0.5~1.1	0.10	0.25	-	0.05	0.15	remainder
5052	0.25	0.40	0.10	0.10	2.2~2.8	0.15~0.35	0.10	-	0.05	0.15	remainder
5754	0.40	0.40	0.10	0.50	2.6~3.6	0.30	0.20	0.15	0.05	0.15	remainder
5083	0.40	0.40	0.10	0.4~1.0	4.0~4.9	0.05~0.25	0.25	0.15	0.05	0.15	remainder

Aluminum alloy is soft and usually alloyed with copper, zinc, magnesium, silicon, manganese and lithium to increase strength. When aluminum alloy is exposed to air, an anti-oxidant coating will be formed instantly to protect products. Aluminum alloy is one of the lightest metals. The application of products ranges from precision technology to daily commodities.

Classification	Alloy	Temper	Size(mm)
Classification	Alloy	Temper	Thickness	Width	I.D.	Max O.D.
Household foil	8011 8111	O	0.01-0.02	200-700	76.2 152.4	450
Cable foil	1050 1145	O	0.1-0.2	200-600	76.2	800
Medical foil	1235 8011 8111	H18 H19	0.018-0.022	400-600	76.2	600
Air-condition foil	1100 8011 3102	H22 H24 H26 H19	0.07-0.2	400-1310	150 200 505	1450
Cigarette foil	1235	O	0.006-0.007	460-1320	76.2	400
Further fabricating foil	8011	O H22 H24 H26 H18	0.012-0.06	300-1300	76.2	1300
Electroic foil	1A99 1A97	H19	0.09-0.15	500-1000	76.2	1450
Electroic foil	3003 3001	H19	0.02-0.05	500-1000	76.2	1450
PS foil	1050	H18	0.14-0.15	600-1470	150 200	1200
Decoration foil	1100 3003	H18	0.026-0.15	1240-1400	150 200	1200

Product Picture of Aluminium Foil

We have our own professional testing equipment, strict quality control system, all goods have to go through three times of strict testing as follows:
    a. all goods strictly inspected during production
    b. all goods must check strictly before packing.
    c. every consignment must be re-inspected before shipment.
You are more than welcome to my factory to inspect the goods at any time.

Main Products of Aluminium
We are mainly dealing with the production of Aluminium Coil/Strip,Aluminium Sheet/Plate,,Aluminium Tread Plate, Color Coated Aluminum Coil/Sheet, Aluminum Perforation and Aluminum Foil.

Aluminium Production lines
Currently, we have hot mills, cold mills, casting mills, coating lines, powder painting lines, tension leveling lines, cutting lines, slitting lines, annealing furnaces, perforating lines, bending machines. We strive to bring our customers high quality aluminum metal products to a cross section of sectors.
Stable and Adequate Inventory
Our capacity is 400,000MT per year totally, among which, 35% are exported to overseas.

Detailed Picture of Our Factory & Warehouse
We assure that you are getting the best aluminum products at a competitive price and we will be at your service meeting all your specifications and needs.

Packing	Excellent package:Anti-water paper and plastic film+ covered by iron sheet+ strapped with minthree strapping strips+fixed on the iron or wooden pallets by strapping strips
Shipping	1.Shipping by containers
Shipping	2.Shipping by bulk ship
Container Size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
	40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
	40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High)
Loading	20feet container load 25-27tons coils whose length is under 5.8m
Loading	40feet container load 25-27tons coils whose length is under 11.8m

Aluminum and aluminum alloy foil can be widely applied in containers, packaging, household & institutional foil, food service products, foil building products, aluminum foil capacitors, aluminum foil finstock, aluminum foil strip conductor, aluminum honeycomb, aluminum foil printing plates, nameplates & product labels, caul stock, foil printing stocks, etc

SGS,ISO,TUV,CE certified outstanding supplier with 18 years experiences ,which has been exported to almost 100 countries with more than 50 kinds of products.

1.Q: Are you a manufacturer?
A:Yes, we are manufacturers. We have our own factory and our own company. I believe we will be the most suitable supplier for you.

2. Q: Do you have quality control system?
A: Yes, we have ISO, BV, MTC certifications and our own quality control laboratory.Third party testing services are also available

3. Q: How long is your delivery time?
A: Generally it is 7-10 workdays if we have the exact goods in our stock. If not, it will take around 15-20 days to get goods ready for delivery.

4. Q: Can we get some samples for free?
A: Yes,you can, But we don't pay for delivery.

5.Q:Can you provide OEM or ODM service ?
A:Yes, we can.

6. Q: What is your after-sale service?
A: We provide after-sale service and offer 100% guarantee on our products.

7.Q: What kind of terms of payment?
A:T/T, L/C are available.
